HMB-2102I
HD Dome Camera.
1/3" 2.1 Megapixel Sony HD Image Sensor
2DNR / 3DNR LEVEL (0~100)SMART NR
4mm MEGAPIXEL LENS / IR LED 24EA
0.02LUX (SENS-UPⅹ30)
DC 12V(±10%)
Specifications For HMB-2102I
| Item | HMB-2102I Series | |||||
|---|---|---|---|---|---|---|
| Imaging Sensor | 1/3" 2.1 Megapixel Sony HD Image Sensor | |||||
| Effective Pixels | 1936(H) x 1097(V) | |||||
| Scanning System | Progressive | |||||
| Video Output | HD-SDI x1, BNC x1, 75Ω Composite | |||||
| S/N Ratio | More than 50㏈ | |||||
| Min. Illumination | 0.02LUX (SENS-UPⅹ30) | |||||
| IRIS Adjustment | DC / MANUAL | |||||
| Lens | 6mm MEGAPIXEL LENS | |||||
| Electronic Shutter | AUTO |
|||||
| Backlight Compensation | AUTO | |||||
| Day & Night | AUTO | |||||
| Auto Gain Control | AUTO | |||||
| White Balance | AUTO | |||||
| IR LED | IR LED 48EA | |||||
| International Protection | IP66 | |||||
| Input Voltage | DC 12V(±10%) | |||||
| Power Consumption | IR OFF : 250mA(MAX) / IR ON : 800mA(MAX) | |||||
| Operating Temp. / Hum. | -10℃~ +50℃ / MAX 90% RH | |||||
| Storage Temp. / Hum. | -20℃~ +60℃ / MAX 90% RH | |||||
