Smart Security
HMS-2100
HD Box Camera
1/3" 2.1Megapixel Sony HD Image Sensor
2DNR / 3DNR / SMART NR / TDN
Varifocal 3~11mm Lens
OSD Controller, 3-Axis Structure Function
0.02LUX (SENS-UPⅹ30)
DC 12V(±10%)
Specifications For HMS-2100
| Item | HMS-2100 | |||||
|---|---|---|---|---|---|---|
| Imaging Sensor | 1/3" 2.1Megapixel Sony HD Image Sensor | |||||
| Effective Pixels | 1936(H) x 1097(V) | |||||
| Scanning System | Progressive | |||||
| Video Output | HD-SDI x1, BNC x1, 75Ω Composite | |||||
| S/N Ratio | More than 50㏈ | |||||
| Min. Illumination | 0.02LUX (SENS-UPⅹ30) | |||||
| IRIS Adjustment | DC / MANUAL | |||||
| Lens | C/CS Mount | |||||
| Electronic Shutter | OFF/AUTO(1/30 ~ 1/50,000 Sec) FLK MANUAL(ⅹ2~ⅹ30) |
OFF/AUTO(1/25 ~ 1/50,000 Sec) FLK MANUAL(ⅹ2~ⅹ30) |
||||
| OSD Language | ENG / CHN1 / CHN2 / JPN | |||||
| Backlight Compensation | BLC / HLC / HSBLS | |||||
| Day & Night | AUTO / B/W(IR SMART) / COLOR / EXT | |||||
| Auto Gain Control | LOW / MEDDLE / HIGH | |||||
| White Balance | AWC→ SET KEY / MANUAL-BLUE, RED(1~100) / INDOOR / OUTDOOR | |||||
| Privacy Masking | ON / OFF (Programmable 8 zone) | |||||
| DNR | 2DNR / 3DNR LEVEL(0~100) Adjustment / SMART NR | |||||
| ACCE | OFF / LOW / MEDDLE / HIGH | |||||
| DEFOG | OFF / LOW / MEDDLE / HIGH | |||||
| Digital Zoom | OFF/ ON(ⅹ2~ⅹ62) OFF | |||||
| SENS-UP | OFF / AUTO / X2~X30 | |||||
| Motion | 3 AREA | |||||
| Digital Effect | OFF / V-FLIP / MIRROR / ROTATE | |||||
| DEFECT | LIVE DPC ( ON, OFF, AUTO) | |||||
| Communication | RS 485 (OPTIONAL) | |||||
| Input Voltage | DC 12V(±10%) | |||||
| Power Consumption | 250mA (MAX) | |||||
| Operating Temp. / Hum. | -10℃~ +50℃ / MAX 90% RH | |||||
| Storage Temp. / Hum. | -20℃~ +60℃ / MAX 90% RH | |||||
