HMD-2100
HD Dome Camera.
1/3" 2.1Megapixel Sony HD Image Sensor
2DNR / 3DNR / SMART NR
3-Axis Structure Function
0.02LUX (SENS-UPⅹ30)
DC 12V(±10%)
Specifications For HMD-2100
| Item | HMD-2100 Series | |||||
|---|---|---|---|---|---|---|
| Imaging Sensor | 1/3" 2.1Megapixel Sony HD Image Sensor | |||||
| Effective Pixels | 1936(H) x 1097(V) | |||||
| Scanning System | Progressive | |||||
| Video Output | HD-SDI x1, BNC x1, 75Ω Composite | |||||
| S/N Ratio | More than 50㏈ | |||||
| Min. Illumination | 0.02LUX (SENS-UPⅹ30) | |||||
| IRIS Adjustment | DC / MANUAL | |||||
| Lens | 3.7mm MEGAPIXEL LENS | |||||
| Electronic Shutter | AUTO | |||||
| Backlight Compensation | AUTO | |||||
| Day & Night | AUTO | |||||
| Auto Gain Control | AUTO | |||||
| White Balance | AUTO | |||||
| Input Voltage | DC 12V(±10%) | |||||
| Power Consumption | 250mA (MAX) | |||||
| Operating Temp. / Hum. | -10℃~ +50℃ / MAX 90% RH | |||||
| Storage Temp. / Hum. | -20℃~ +60℃ / MAX 90% RH | |||||
