HMH-2100I

HD Housing Camera.


1/3" 2.1Megapixel Sony HD Image Sensor
2DNR / 3DNR LEVEL(0~100) Adjustment / SMART NR
0.02LUX (SENS-UPⅹ30) / IR LED 66EA
3.7mm MEGAPIXEL LENS
DC 12V(±10%)

Specifications For HMH-2100I

Item HMH-2101I
Imaging Sensor 1/3" 2.1Megapixel Sony HD Image Sensor
Effective Pixels 1936(H) x 1097(V)
Scanning System Progressive
Video Output HD-SDI x1, BNC x1, 75Ω Composite
S/N Ratio More than 50㏈
Min. Illumination 0.02LUX (SENS-UPⅹ30)
IRIS Adjustment DC / MANUAL
Lens 3.7mm MEGAPIXEL LENS
Electronic Shutter OFF/AUTO(1/30 ~ 1/50,000 Sec)
FLK MANUAL(ⅹ2~ⅹ30)
OFF/AUTO(1/25 ~ 1/50,000 Sec)
FLK MANUAL(ⅹ2~ⅹ30)
OSD Language ENG / CHN1 / CHN2 / JPN
Backlight Compensation BLC / HLC / HSBLS
Day & Night AUTO / B/W(IR SMART) / COLOR / EXT
Auto Gain Control LOW / MEDDLE / HIGH
White Balance AWC→ SET KEY / MANUAL-BLUE, RED(1~100) / INDOOR / OUTDOOR
Privacy Masking ON / OFF (Programmable 8 zone)
DNR 2DNR / 3DNR LEVEL(0~100) Adjustment / SMART NR
ACCE OFF / LOW / MEDDLE / HIGH
DEFOG OFF / LOW / MEDDLE / HIGH
Digital Zoom OFF/ ON(ⅹ2~ⅹ62) OFF
SENS-UP OFF / AUTO / X2~X30
Motion 3 AREA
Digital Effect OFF / V-FLIP / MIRROR / ROTATE
DEFECT LIVE DPC ( ON, OFF, AUTO)
Communication  RS 485 (OPTIONAL)
IR LED IR LED 66EA
International Protection IP66
Input Voltage DC 12V(±10%)
Power Consumption IR OFF : 250mA / IR ON : 800mA(MAX)
Operating Temp. / Hum. -10℃~ +50℃ / MAX 90% RH
Storage Temp. / Hum. -20℃~ +60℃ / MAX 90% RH
