HTD-2212AHD
Analog HD IR Indoor Dome Camera.
1/3” 1.3Megapixel CMOS
0.02Lux at F1.2(Sens-up x30)
2.8~11mm DC Auto Iris Varifocal Lens (ICR Type)
Built-in OSD Controller & 2nd BNC Connector
Digital Noise Reduction
ICR Filter Change Function
3-Axis Structure
Specifications For HTD-2212AHD
| Image Sensor | 1/3” 1.3Megapixel CMOS | |||||
| Effective Pixel | 1305(H) X 1049(V) = 1,368,945 (pixel) | |||||
| Scanning System | Progressive Scan | |||||
| Video Output Mode | 720P(1280X720) 25P/30P | |||||
| Video Output Level | AHD1.0 | |||||
| S/N (Y Signal) | More Than 50dB | |||||
| Min. Illumination | 0.02Lux at F1.2(Sens-up x30) | |||||
| Lens | 2.8~11mm DC Auto Iris Varifocal Lens(ICR Type) |
3.6mm Fixed Lens | ||||
| Electronic Shutter | AUTO/MANUAL (NTSC: 1/30~1/50,000sec), PAL: 1/25sec~1/50,000sec) |
|||||
| OSD Language | ENG/CHI1/CHI2/GER/FRE/ITA/SPA/POL/RUS/ POR/DUT/TUR/KOR/JAP/HEB/ARA |
|||||
| Backlight Compensation | BLC / HSBLC / OFF | |||||
| Day & Night | AUTO / COLOR / BW / EXT | |||||
| D-WDR | ON / OFF / AUTO | |||||
| Auto Gain Control | LEVEL 1~15(ADJ) | |||||
| White Balance | ATW / AWC-SET / INDOOR / OUTDOOR / MANAUL / AWB | |||||
| Privacy Masking | OFF / ON (4 Points) | |||||
| DNR | 2DNR+3DNR | |||||
| Defog | OFF / AUTO | |||||
| Dead Pixel Compensation | LIVE DPC / WHITE DPC / BLACK DPC | |||||
| SENS-UP | AUTO/ OFF (X2~ X30) | |||||
| Motion Detection | OFF / ON (4 Points) | |||||
| Digital Effect | FREEZE / MIRROR / NEG.IMAGE | |||||
| Communication | OPTION(PELCO-D/P) | |||||
| IR LED | 24EA | |||||
| Input Voltage | DC 12V(±10%) ONLY | |||||
| Power Consumption | IR OFF : 150mA (MAX) / IR ON : 300mA (MAX) | |||||
| Operating Temp. / Hum. | -10ºC~ +50ºC / MAX 90% RH | |||||
| Storage Temp. / Hum. | -20ºC~ +60ºC / MAX 90% RH | |||||
